Product Description
| Tire Size | Ply Rating | Measuring Rim Width | Approved Rim Width | Max. Air Pressure | Max. Load | |||||
|---|---|---|---|---|---|---|---|---|---|---|
| bar | psi | kg | lbs | |||||||
| Tubeless | ||||||||||
| 245/70 R19.5 |  137M |
16 | 7.50 | 6.75 | 8.30 | 120 | 2300 | 5070 | ||
| 245/70 R19.5 |  135 |
2200 | 4850 | |||||||
| 245/70 R19.5 | 136M |
14 | 7.50 | 6.75 | 7.60 | 110 | 2240 | 4940 | ||
| 245/70 R19.5 | 134 |
2120 | 4675 | |||||||
| 11 R22.5 | 148L |
16 | 8.25 | 7.50 | 8.30 | 120 | 3000 | 6610 | ||
| 11 R22.5 | 145 |
2725 | 6005 | |||||||
| * | 11 R22.5 | 148L |
16 | 8.25 | 7.50 | 8.30 | 120 | 3000 | 6610 | |
| * | 11 R22.5 | 145 |
2725 | 6005 | ||||||
| 12 R22.5 | 152L |
16 | 9.00 | 8.25 | 8.30 | 120 | 3350 | 7390 | ||
| 12 R22.5 | 148 |
3075 | 6780 | |||||||
| * | 12 R22.5 | 152L |
16 | 9.00 | 8.25 | 8.30 | 120 | 3350 | 7390 | |
| * | 12 R22.5 | 148 |
3075 | 6780 | ||||||
| * | 295/80 R22.5 | 152M |
16 | 9.00 | 8.25 | 8.60 | 125 | 3550 | 7830 | |
| * | 295/80 R22.5 | 148 |
3150 | 6945 | ||||||
| 295/80 R22.5 | 152M |
16 | 9.00 | 8.25 | 8.60 | 125 | 3550 | 7830 | ||
| 295/80 R22.5 | 148 |
3150 | 6945 | |||||||
| 315/80 R22.5 | 156L |
20 | 9.00 | 9.75 | 9.00 | 130 | 4080 | 9000 | ||
| 315/80 R22.5 | 150 |
3750 | 8270 | |||||||
| 315/80 R22.5 | 154M |
18 | 9.00 | 9.75 | 8.30 | 120 | 3750 | 8270 | ||
| 315/80 R22.5 | 150 |
3450 | 7610 | |||||||
| * | 315/80 R22.5 | 154M |
18 | 9.00 | 9.75 | 9.00 | 120 | 3750 | 8270 | |
| * | 315/80 R22.5 | 151 |
3450 | 7608 | ||||||
| Tube Type | ||||||||||
| * | 11.00 R20 | 150K |
16 | 8.00 | 8.50 | 8.30 | 120 | 3350 | 7390 | |
| * | 11.00 R20 | 147 |
3075 | 6780 | ||||||
