Product Description
| Tire Size | Ply Rating | Measuring Rim Width | Approved Rim Width | Max. Air Pressure | Max. Load | |||||
|---|---|---|---|---|---|---|---|---|---|---|
| bar | psi | kg | lbs | |||||||
| Tubeless | ||||||||||
| 8 R17.5 |  117L |
10 | 6.00 | 5.25 | 6.60 | 95 | 1320 | 2910 | ||
| 8 R17.5 |  116 |
1250 | 2755 | |||||||
| 8.5 R17.5 | 121M |
12 | 6.00 | 5.25 | 6.20 | 90 | 1450 | 3195 | ||
| 8.5 R17.5 | 120 |
1400 | 3085 | |||||||
| 9.5 R17.5 | 129L |
12 | 6.75 | 6.00 | 7.80 | 110 | 1850 | 4080 | ||
| 9.5 R17.5 | 127 |
1750 | 3860 | |||||||
| 205/75 R17.5 | 124M |
10 | 6.00 | 5.25 | 7.50 | 110 | 1600 | 3525 | ||
| 205/75 R17.5 | 122 |
1500 | 3305 | |||||||
| 215/75 R17.5 | 126M |
12 | 6.00 | 6.75 | 7.25 | 105 | 1700 | 3750 | ||
| 215/75 R17.5 | 124 |
1600 | 3530 | |||||||
| 225/80 R17.5 | 123L |
14 | 6.75 | 6.00 | 7.00 | 100 | 1550 | 3415 | ||
| 225/80 R17.5 | 122 |
1500 | 3305 | |||||||
| 225/75 R17.5 | 129M |
12 | 6.75 | 6.00 | 7.25 | 105 | 1850 | 4080 | ||
| 225/75 R17.5 | 127 |
1750 | 3860 | |||||||
| 235/75 R17.5 | 132M |
14 | 6.75 | 7.50 | 8.00 | 115 | 2000 | 4410 | ||
| 235/75 R17.5 | 130 |
1900 | 4190 | |||||||
| 245/70 R17.5 | 136M |
16 | 7.50 | 6.75 | 8.60 | 125 | 2240 | 4940 | ||
| 245/70 R17.5 | 134 |
2120 | 4670 | |||||||
| 265/70 R17.5 | 138M |
14 | 7.50 | 7.50 | 7.60 | 110 | 2360 | 5205 | ||
| 265/70 R17.5 | 136 |
2240 | 4940 | |||||||
| 225/70 R19.5 | 128L |
14 | 6.75 | 6.00 | 7.60 | 110 | 1800 | 3970 | ||
| 225/70 R19.5 | 126 |
1700 | 3750 | |||||||
| 225/70 R19.5 | 125L |
12 | 6.75 | 6.00 | 6.60 | 95 | 1650 | 3640 | ||
| 225/70 R19.5 | 123 |
1550 | 3415 | |||||||
| 245/70 R19.5 | 133M |
14 | 7.50 | 6.75 | 7.60 | 110 | 2060 | 4540 | ||
| 245/70 R19.5 | 131 |
1985 | 4375 | |||||||
| 245/70 R19.5 | 136M |
16 | 7.50 | 6.75 | 8.30 | 120 | 2240 | 4940 | ||
| 245/70 R19.5 | 134 |
2120 | 4670 | |||||||
| 265/70 R19.5 | 140M |
16 | 7.50 | 6.75 | 7.95 | 115 | 2500 | 5510 | ||
| 265/70 R19.5 | 138 |
2360 | 5200 | |||||||
| 285/70 R19.5 | 145M |
16 | 8.50 | 7.50 | 8.60 | 125 | 2900 | 6395 | ||
| 285/70 R19.5 | 143 |
2725 | 6005 | |||||||
| 305/70 R19.5 | 148M |
16 | 9.00 | 8.25 | 8.65 | 125 | 3150 | 6945 | ||
| 305/70 R19.5 | 145 |
2900 | 6395 | |||||||
| * | 12 R22.5 | 152L |
16 | 9.00 | 8.25 | 8.30 | 120 | 3350 | 7390 | |
| * | 12 R22.5 | 148 |
3075 | 6780 | ||||||
| 275/70 R22.5 | 148M |
16 | 8.25 | 7.50 | 8.65 | 125 | 3150 | 6945 | ||
| 275/70 R22.5 | 145 |
2900 | 6395 | |||||||
| 275/70 R22.5 | 148L |
18 | 8.25 | 7.50 | 9.00 | 130 | 3150 | 6945 | ||
| 275/70 R22.5 | 145 |
2900 | 6395 | |||||||
| * | 295/80 R22.5 | 152M |
16 | 9.00 | 8.25 | 8.30 | 120 | 3550 | 7830 | |
| * | 295/80 R22.5 | 148 |
3150 | 6945 | ||||||
| 295/60 R22.5 | 150K |
16 | 9.00 | 9.75 | 9.00 | 130 | 3350 | 7390 | ||
| 295/60 R22.5 | 147 |
3075 | 6780 | |||||||
| 305/70 R22.5 | 152L |
16 | 9.00 | 8.25 | 8.30 | 120 | 3350 | 7390 | ||
| 305/70 R22.5 | 148 |
3150 | 6945 | |||||||
| 315/60 R22.5 | 152L |
16 | 9.00 | 9.75 | 9.00 | 130 | 3550 | 7830 | ||
| 315/60 R22.5 | 148 |
3150 | 6940 | |||||||
| 315/80 R22.5 | 156L |
20 | 9.00 | 9.75 | 9.00 | 130 | 4082 | 9000 | ||
| 315/80 R22.5 | 150 |
3750 | 8270 | |||||||
| 315/70 R22.5 | 154L |
16 | 9.00 | 9.75 | 8.65 | 125 | 3550 | 7830 | ||
| 315/70 R22.5 | 150 |
3150 | 6945 | |||||||
| 315/80 R22.5 | 156L |
18 | 9.00 | 9.75 | 8.30 | 120 | 3750 | 8270 | ||
| 315/80 R22.5 | 150 |
3350 | 7390 | |||||||
| Tube Type | ||||||||||
| 11.00 R22 | 152K |
16 | 8.00 | 8.50 | 8.00 | 120 | 3550 | 7830 | ||
| 11.00 R22 | 149 |
3250 | 7160 | |||||||
